Zero Ohm Network Resistors

Finn et stort utvalg av Zero Ohm Network Resistors hos Farnell Norge. Vi lagerfører et stort utvalg av Zero Ohm Network Resistors, inkludert nye og mest populære produkter fra verdens beste produsenter, inkludert: Panasonic, Bourns, Multicomp Pro, Yageo & Yageo / Partner Stock.

Produsentens varenummer	Bestillingskode	Produsent / Beskrivelse	Pris for	Pris (eks. MVA)	Resistor Case / Package	Resistor Technology	Network Circuit Type	Resistor Terminals	No. of Resistors	Current Rating	Power Rating per Resistor	Resistor Mounting	Product Range	Product Length	Product Width	Product Height	Operating Temperature Min	Operating Temperature Max

MCPNF43JT-XR0R0	4006482 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Zero Ohm Network Resistor Jumper 0603 [1608 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,409 100+kr 0,264 500+kr 0,209 1000+kr 0,164 2500+kr 0,147	0603 [1608 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	-	Surface Mount Device	-	3.2mm	1.55mm	0.55mm	-55°C	155°C
TC164-JR-070RL	9234675 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,588 100+kr 0,388 500+kr 0,289 1000+kr 0,266 2500+kr 0,260	1206 [3216 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	62.5mW	Surface Mount Device	TC Series	3.2mm	1.6mm	0.6mm	-55°C	155°C
EXB28VR000X	2060028 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,496 100+kr 0,354 500+kr 0,320 2500+kr 0,274 5000+kr 0,268	0402 [1005 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	EXB-28V Series	1.02mm	0.5mm	0.35mm	-55°C	125°C
CAT16-000J4LF	2321719 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,478 100+kr 0,344 500+kr 0,310 1000+kr 0,284 2500+kr 0,264	1206 [3216 Metric]	-	Isolated	Concave	4Resistors	-	62mW	Surface Mount Device	CAT16 Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
TC124-JR-070RL	1779399 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,591 100+kr 0,387 500+kr 0,296 2500+kr 0,262 5000+kr 0,205	0402 [1005 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	62.5mW	Surface Mount Device	TC Series	1.02mm	0.5mm	0.4mm	-55°C	125°C
YC164-JR-070RL	9234381 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,396 100+kr 0,254 500+kr 0,198 1000+kr 0,170 2500+kr 0,167	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	62.5mW	Surface Mount Device	YC Series	3.2mm	1.6mm	0.6mm	-55°C	155°C
CAY16-000J4LF	2321738 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,594 100+kr 0,368 500+kr 0,321 1000+kr 0,285 2500+kr 0,255	1206 [3216 Metric]	-	Isolated	Convex	4Resistors	-	62mW	Surface Mount Device	CAY16 Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
EXB38VR000V	2060083 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,664 100+kr 0,431 500+kr 0,326 1000+kr 0,292 2500+kr 0,286	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	EXB-38V Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
EXB2HVR000V	2060063 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 8 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 1,750 100+kr 1,410 500+kr 1,170 1000+kr 1,090 2500+kr 0,991	0402 [1005 Metric]	Thick Film	Isolated	Convex	8Resistors	1A	63mW	Surface Mount Device	EXB-2HV Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
YC248-JR-070RL	1377038 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 0616 [1640 Metric] Thick Film Isolated Convex 8 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 1,020 100+kr 0,669 500+kr 0,518 1000+kr 0,452 2500+kr 0,443	0616 [1640 Metric]	Thick Film	Isolated	Convex	8Resistors	2A	62.5mW	Surface Mount Device	YC Series	4mm	1.6mm	0.45mm	-55°C	155°C
YC122-JR-070RL	3497067 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 0404 [1010 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,225 100+kr 0,151 500+kr 0,113 2500+kr 0,104 5000+kr 0,0943	0404 [1010 Metric]	Thick Film	Isolated	Convex	2Resistors	500mA	62.5mW	Surface Mount Device	YC Series	1mm	1mm	0.3mm	-55°C	155°C
CAY10-000J4LF	2663510 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,236 100+kr 0,171 500+kr 0,138 2500+kr 0,114 5000+kr 0,111 Flere priser ....	0804 [2010 Metric]	-	Isolated	Convex	4Resistors	-	62.5mW	Surface Mount Device	CAY10 Series	2mm	1mm	0.35mm	-55°C	125°C
CAT10-000J4LF	2908138 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Isolated Concave 4 Resistors	Each	10+kr 0,688 100+kr 0,424 500+kr 0,376 2500+kr 0,304 5000+kr 0,288 Flere priser ....	0804 [2010 Metric]	-	Isolated	Concave	4Resistors	-	63mW	Surface Mount Device	CAT10 Series	2mm	1mm	0.4mm	-55°C	125°C
CAY10A-000J2LF	3769775 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 0404 [1010 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,888 100+kr 0,365 500+kr 0,230 2500+kr 0,206 5000+kr 0,158 Flere priser ....	0404 [1010 Metric]	Thick Film	Isolated	Convex	2Resistors	1A	63mW	Surface Mount Device	CAY10A-LF Series	1mm	1mm	0.35mm	-55°C	125°C
CAY10A-000J4LF	3769776 Data Sheet RoHS Date/Lot Code	BOURNS Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 1,090 100+kr 0,383 500+kr 0,276 2500+kr 0,215 5000+kr 0,195 Flere priser ....	0804 [2010 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	CAY10A-LF Series	2mm	1mm	0.4mm	-55°C	125°C
EXB24VR000X	4014621 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,510 100+kr 0,336 500+kr 0,304 2500+kr 0,259 5000+kr 0,247 Flere priser ....	0402 [1005 Metric]	Thick Film	Isolated	Convex	2Resistors	1A	63mW	Surface Mount Device	EXB-24V Series	1mm	1mm	0.35mm	-55°C	125°C
EXBN8VR000X	4757250 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	1+kr 1,440 10+kr 0,902 20+kr 0,883	0402 [1005 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	31mW	Surface Mount Device	EXB-N8V Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
EXB14VR000X	4632629 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0302 [0806 Metric] Thick Film Isolated Convex 2 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 1,330 100+kr 0,979 500+kr 0,807 2500+kr 0,753 5000+kr 0,685 Flere priser ....	0302 [0806 Metric]	Thick Film	Isolated	Convex	2Resistors	500mA	31mW	Surface Mount Device	EXB-14V Series	0.8mm	0.6mm	0.35mm	-55°C	125°C
EXBN8VR000X	4757250RL Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0402 [1005 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	20+kr 0,883	-	-	-	-	-	-	-	-	-	-	-	-	-	-
EXBV8VR000V	4544164 Data Sheet RoHS Date/Lot Code	PANASONIC Zero Ohm Network Resistor Jumper 0603 [1608 Metric] Thick Film Isolated Concave 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 1,210 100+kr 0,799 500+kr 0,610 2500+kr 0,521 5000+kr 0,422 Flere priser ....	0603 [1608 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	63mW	Surface Mount Device	EXB-V8V Series	1.6mm	0.85mm	0.6mm	-55°C	125°C
MP000986	3228734 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Zero Ohm Network Resistor Jumper 1206 [3216 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	1+kr 0,229	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	100mW	Surface Mount Device	-	3.2mm	1.6mm	0.55mm	-55°C	155°C
CAT16A-000J4LF	3754737 Data Sheet RoHS Date/Lot Code	BOURNS RES N/W ISOLATED 0R 0.063W 3216	Each (Supplied on Cut Tape) Cut Tape	1+kr 1,910 25+kr 1,020 50+kr 0,811 100+kr 0,593 250+kr 0,468 Flere priser ....	1206 [3216 Metric]	Thick Film	Isolated	Concave	4Resistors	1A	63mW	Surface Mount Device	CAT16A-LF Series	3.2mm	1.6mm	0.55mm	-55°C	125°C
CAY16A-000J4LF	3754794 Data Sheet RoHS Date/Lot Code	BOURNS RES N/W ISOLATED 0R 0.063W 3216	Each (Supplied on Cut Tape) Cut Tape	1+kr 1,890 25+kr 1,250 100+kr 0,729 250+kr 0,586 500+kr 0,503 Flere priser ....	1206 [3216 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	63mW	Surface Mount Device	CAY16A-LF Series	3.2mm	1.6mm	0.5mm	-55°C	125°C
YC104-JR-070RL	4774915 Data Sheet RoHS	YAGEO / PARTNER STOCK ZERO OHM NETWORK RESISTORS	Each	10000+kr 0,372 30000+kr 0,365	-	-	-	-	-	-	-	-	-	-	-	-	-	-
YC124-JR-070RL	9235221 Data Sheet RoHS Date/Lot Code	YAGEO Zero Ohm Network Resistor Jumper 0804 [2010 Metric] Thick Film Isolated Convex 4 Resistors	Each (Supplied on Cut Tape) Cut Tape	10+kr 0,366 100+kr 0,235 500+kr 0,179 2500+kr 0,159 5000+kr 0,131	0804 [2010 Metric]	Thick Film	Isolated	Convex	4Resistors	1A	62.5mW	Surface Mount Device	YC Series	1.02mm	0.5mm	0.45mm	-55°C	125°C
