0034405.
Multicore Cable, Unitronic® LiYCY, Screened, 5 Core, 24 AWG, 0.25 mm², 164 ft, 50 m
Trenger du mer?
| Antall | |
|---|---|
| 1+ | kr 998,410 |
| 5+ | kr 978,410 |
| 10+ | kr 958,520 |
Produktinformasjon
Alternativer for 0034405.
1 produkt funnet
Produktoversikt
The 0034405 is a 50m 5-core shielded Data Transmission Cable with fine wire strands of bare copper wires, grey PVC jacket and 24AWG wire. Screened data transmission cable with colour code according to DIN 47100. Overall braid minimises electrical interference, multifunctional application possibilities. The UNITRONIC® LiYCY is a screened data cable for low frequency applications. The shielded cable is designed for fixed installation and for conditional flexible use. It is used in dry and damp interiors but not appropriate for outside usage. The screen provides protection against electromagnetic interferences.
- CPR: Eca
- Fine-wire/multi-wire strand made of bare copper wires
- PVC core insulation
- Tinned-copper braiding
- PVC outer sheath
- Pebble grey (RAL 7032) outer sheath
- Small dimensions
- Flame-retardant according to IEC 60332-1-2
Applikasjoner
Computers & Computer Peripherals, Sensing & Instrumentation, Commercial, Industrial
Tekniske spesifikasjoner
Screened
24AWG
164ft
Grey
Copper
5.6mm
Unitronic LiYCY
5Core
0.25mm²
50m
7 x 0.511mm
PVC
350V
Teknisk dokumentasjon (1)
Lovgivning og miljø
Land der forrige produksjonsprosess av betydning ble fortattOpprinnelsesland:Bulgaria
Land der forrige produksjonsprosess av betydning ble fortatt
RoHS
RoHS
Sertifikat for produktsamsvar
